JT-50 Protection Filter Element 0714660 | Fire-Resistant Oil Pre-Protection Filtration

Product Description

The 0714660 protection filter element is an OEM-grade protection filter matched for JT-50 oil purifiers, compatible with oil purification equipment of 50L/min (3000L/h) flow rate. Serving as a pre-filter / post-filter protection component, it mainly captures large particulate contaminants and media shedding debris in oil. It protects precision internal components, vacuum pump and downstream regeneration filter elements of the oil purifier. It prevents large contaminants from flowing downstream which may clog precision filter elements or damage equipment. It ensures continuous and stable operation of the JT-50 oil purifier and is an essential spare part for daily maintenance of the oil purifier.

Product Advantages

Original mounting dimensions: Part number 0714660, fully compatible with JT-50 oil purifier, direct replacement without pipeline modification. Graded composite filter media: Large dirt holding capacity with gentle pressure differential rise, extending service life of downstream precision filter elements. Robust structure: Reliable bonding of filter layers, impact resistance. The filter media is not easy to damage or shed fibers to avoid secondary oil contamination. Dependable sealing performance: Matched oil-resistant seals prevent bypass leakage and ensure full flow filtration. Suitable for high-flow working conditions: Designed for 50L/min oil purifier flow, high oil throughput without excessive resistance and no impact on overall processing efficiency.

Technical Parameters

· Model: 0714660

· Compatible Equipment: JT-50 Oil Purifier

· Rated Flow: 50L/min (3000L/h)

· Filter Media: Composite fiberglass media

· Filtration Accuracy: 20 μm

· Seal: Oil-resistant rubber seal

· Applicable Media: Fire-resistant oil, hydraulic oil, lubricating oil and other industrial oils

· Nominal Pressure: ≤0.35 MPa

· Executive Standard: GB/T 20080

Application Scope

Used together with JT-50 mobile oil purifier as the protection filtration unit of the whole machine. Applied for oil purification in power plants and industrial hydraulic stations. It traps solid particles and filter media debris during oil regeneration process to protect the main unit, vacuum pump and downstream acid removal & resistivity-improving precision filter elements of the oil purifier. Suitable for filtration and purification of phosphate ester fire-resistant oil, turbine oil, hydraulic oil and other oils.
