ZNGL02010201 Filter Element, Glass Fiber Pleated Cartridge for Duplex Filter, Power Plant Oil Station Lube Filter

Product Introduction

ZNGL02010201 is a dedicated glass-fiber pleated cartridge for ZNGL duplex filters, widely used in power-plant lube oil stations. It removes metal particles and sludge to protect oil pumps, gears and bearings. Supports on-line hot-swap without shutdown, direct OEM-size replacement.

Specifications

· Filtration Rating: 20μm

· Filter Media: Composite glass fiber

· Sealing: Oilresistant sealing gasket

· Fluid Media: Lubricating oil, hydraulic oil, turbine oil

· Nominal Pressure: 1.6 MPa

· Max. Allowable Differential Pressure: 0.35 MPa

· Operating Temperature: -25℃～95℃

Advantages

1. Composite glass-fiber media, high dirt-holding capacity, stable filtration performance

2. Stainless-steel inner core, high pressure-shock resistance, zero fiber shedding

3. Pleated construction for large filter area, good flow capacity and low initial pressure drop

4. Reliable sealing to prevent fluid bypass and leakage

Application Fields

Applied to turbine lube oil stations in power plants, lube & hydraulic oil stations in steel and chemical plants, and reducer oilsupply systems; serves as replacement spare part for ZNGLseries duplex filters.
